無需軟件PDF/EXCEL導出一次性U盤藥品食品冷鏈運輸溫度記錄儀

1. 產品概述

PDF溫度記錄儀是杭州西府科技有限公司專門針對醫藥、疫苗、血液、冷鏈物流、食品、化工、農業、氣象、畜牧等行業開發的一款產品。

1. General

The PDF temperature data logger was designed specifically for medical industry, vaccine, blood, cold-chain logistics, food, chemical industry, agriculture, metrology and animal husbandry by Hangzhou Xifu Technology Co., LTD.

The PDF temperature logger is completely waterproof (IP65), yet light and comfortable, can works nearly anywhere.

There’s no need to install driver program when use it. You can plug the logger directly into the computer USB port. The computer can generate PDF or EXCEL report automatically. Meanwhile, the report has been encrypted in order to ensure the data is complete and reliable.

PDF溫度記錄儀具備IP65防水設計,超薄小巧的設計，可相容于任何使用場合。

客戶使用PDF記錄儀無需安裝驅動程序，記錄完成直接插入電腦USB接口，就能自動生成PDF或EXCEL格式的報告。并且報告被加密，確保資料完整性和安全性。

d

2. 產品特點

（1）IP65防水設計，體積超薄小巧，可相容與任何場合。

（2）免驅動安裝，插入USB接口，自動生成PDF/EXCEL格式的報告，支持Win XP/7/8/10，Mac等多種系統。

（3）嚴格的加密技術生成不可篡改的報告，保證數據的真實性、安全性，符合PDF/A標準。

（4）客戶通過軟件自行配置各種參數（后面升級），比如上、下限值，記錄間隔，延時啟動等。

（5）記錄儀的容量標準為14400組，支持擴容。

（6）報告內容包含數據報表、曲線、MKT值、記錄間隔、記錄天數等內容。報告支持中文簡體、中文繁體、英文等。

（7）支持Mark點功能（最多支持8個Mark點）。

（8）報告文件生成快，導出14400組數據，生成加密的PDF文件只需要30秒左右。

（9）食品級塑封袋，符合食品級應用場所。

（10）鍍金、無鉛噴漆等工藝，保證產品的品質。

（11）通過±30kV靜電ESD測試，保證了產品使用的可靠性。

（12）PDF記錄儀在低溫環境下（-20℃~-30℃）能正常工作，導出文件正常。低溫環境下，PDF記錄儀，9分鐘記錄間隔至少可使用90天。

2. Product features

(1)Completely waterproof (IP65). Light and comfortable. Work nearly anywhere.

(2)Without driver program installation. Plug the logger directly into the UBS port and generate PDF or EXCEL report automatically. Support multiple operating systems, for example, Mac, Win and XP7/8/9/10.

(3)The report will be encrypted. So, the data is complete and reliable to PDF/A standards.

(4)Users can reset various parameters by software, like upper limit value, lower limit value, time interval, time-delay start. Note: This feature will be upgraded in the new version.

(5)The standard capacity is 14400 sets for the logger. But later, users can enlarge the capacity.

(6)The report contains datasheet, curve, MKT value, time interval and the number of days. The report supports simplified Chinese, traditional Chinese and English.

(7)It supports Mark-Point function up to 8 points.

(8)It takes only about 30 seconds to export 14400 sets data and generate encrypted PDF or EXCEL reports.

(9)The plastic-sealed bags are food grade, so it has been extensively used in the fields of food.

(10)By using the gold-plated and lead-free spray paint, the quality of loggers can be therefore guaranteed.

(11)By electrostatic ESD test at ±30kV, the reliability of loggers can be therefore guaranteed.

(12)The PDF data logger can work normally in low temperature environment(-20℃~-30℃). And that, It can be used for at least 90 days with 9 minutes recording interval at low temperature.

3. 技術參數

3. Technical parameter
